Pack Battery specifications
|
No. |
Items | Specifications | Remark | |||
|
1 |
Capacity for assembledcell discharging by 0.2C |
≥5000mAh |
Standard discharging method |
|||
|
2 |
Battery Voltage |
Sea & Land | 7.6-8.0V | Within 10 days from Factory | ||
| Air | 7.4-7.6V | In accordance with the requirements for the airline air battery charge 30% or less. | ||||
|
3 |
Standard charge condition |
0.2C constant current,8.4V constant voltage charge to 8.4V,continue charging till current decline to ≤0.01C (25±3℃) |
||||
|
4 |
Standard discharging method |
0.2C constant current discharge to 6.0V, (25±3℃) |
||||
|
5 |
Maximum charge current |
0.5C |
||||
|
6 |
Maximum discharge current |
1C |
||||
|
8 |
Operation Temperature and relative humidity Range |
Charge | 0~ 15℃ | ≤0.2C |
High/low temperature environment reduce battery charge efficiency and influence battery life. Long time working under 60 ℃ environment will lead to battery abnormal. |
|
| 15~45℃ | ≤0.5C | |||||
|
Discharge |
-20~0℃ | ≤0.2C | ||||
| 0~60℃ | ≤1C | |||||
|
9 |
Internal Impedance |
Assemblage Impedance ≤180mΩ |
Measure two sides of the drawing line after assembling. |
|||
Pack Battery Pack Dimensions
| NO | Items | Units :mm | Remark | |
| 1 | Thickness/厚度 | T | 14.0 | Max. |
| 2 | Width/宽度 | W | 62 | Max. |
| 3 | Height/长度 | H | 94±2 | |
| 4 | Cable Length/引线长度 | L | 100±5 | |
| L1 | 2-3 | |||
