Feature for ICR18650 Lithium Ion Cylindrical Battery 7.4V 2600mah For Outdoor Lighting
1. The rated capacity:2600mAh,The nominal voltage:7.4V.
2. The size for th battery pack:Max 20.5mm*69mm*38.5mm
3. Ths single cell for the pack:energy type ICR18650 2600mAh,2S1P.
4. Have long cycle life.
5. The application for outdorr lighting lithium battery pack,back up battery for outdoor lighting.
Specification
| No. | Item | General Parameter | Remark |
| 1 | Rated Capacity | 2600mAh | Standard discharge(0.2 C5)after standard charge(0.2 C5) |
| 2 |
Minimal Rated Capacity |
2550mAh | |
| 3 | Nominal Voltage | 7.4V | |
| 4 | Life Exception | Higher than 60% of the Initial Capacity of the Cells |
◆Charge: CC@0.2C to 6V, then CV till current to 0.05C ◆Rest: 30min. ◆Discharge: 0.2C to 5.0V ◆Temperature:20±5℃ ◆Carry out 500cycles |
| 5 | Discharge cut-off voltage | ≥6V | 5.0V( recommended) |
| 6 | Charging cut-off voltage | ≤8.4V | 7.3V (recommended) |
| 7 | Cell and assembly method | ICR18650EC-2600mAh | 2S1P |
| 8 | Housing material | PVC |
