14500 (Other Name 14505) ,standard voltage is 3.2V when the battery full charge, the battery is 4.2V
This model capacity is 600mAh, 14500 have vary capacity including of 250-600mah
Very Widely application in solar product field.
Deep cycle , long circle life is about 2000 times
Solar Light,Flashlight
Portable high power devices
Stationary battery backup systems
Grid stabilization energy storage systems
Commercial truck and bus electric vehicles (HEVs)
|
Battery Type |
LiFePO4 |
|
Nominal Voltage |
3.2V |
|
Nominal Capacity |
250mah-600mah |
|
Internal Resistance |
≤45mΩ |
|
Limited Charge Voltage |
3.65V |
|
Charge Method |
CC/CV |
|
Discharge Cut-off Voltage |
2.3V |
|
Max. Charge Current |
1C |
|
Max. Continuous Discharge Current (<30min) |
1C |
|
Pulse Discharge Current (<3s) |
3C |
|
Cycle Life |
> 2000 cycles |
|
Dimension |
Diameter: 14mm |
|
Height: 50mm |
|
|
Weight |
25g |
|
Operation Temperature Range |
Charge: 0~45℃; |
|
Discharge: -20~60℃ |
|
|
Recommended operating temperature: 15℃~35℃ |
|
|
Self-Discharge Rate |
Residual capacity: ≤5%/month; |
50pcs each standard white paper , 8 box for export papaer carton
Tac Support all size for Lifepo4 cell involve various capacity
