| Basic Information |
|
| Model |
CR17505 |
| Type |
Lithium Manganese Dioxide Battery (LiMnO₂) |
| Voltage |
3.0V |
| Capacity |
3000mAh |
| Dimensions & Weight |
|
| Dimensions |
Diameter 17.5mm, Height 50.5mm (may vary slightly by manufacturer) |
| Weight |
Approximately 30-40g |
| Electrochemical Performance |
|
| Nominal Voltage |
3.0V |
| Discharge Cut-off Voltage |
2.0V |
| Charging Method |
Non-rechargeable (Primary Battery) |
| Discharge Characteristics |
Stable discharge voltage platform, suitable for low-power devices |
| Environmental Adaptability |
|
| Operating Temperature Range |
-20℃ to +60℃ (some models can reach -40℃ to +85℃) |
| Storage Temperature Range |
-20℃ to +40℃ |
| Humidity Adaptability |
Relative humidity 5% to 95% |
| Safety Features |
|
| Over-discharge Protection |
Built-in protection circuit |
| Short-circuit Protection |
Equipped with short-circuit protection function |
| Leak-proof Design |
Sealed structure to prevent electrolyte leakage |
| Other Features |
|
| Self-discharge Rate |
Low self-discharge rate, suitable for long-term storage and backup |
| Shelf Life |
3-5 years (under recommended storage conditions) |
| Certifications |
Complies with international certification standards such as RoHS, CE, UL |
