Item |
General Parameter |
Remark |
|
Normal Capacity
|
600MAh |
Standard charge by（0.2C）to 10.96V, then CV till current to 0.02C, Standard discharge by（0.2C）to 7.5V;
|
|
Minimal Capacity
|
5.5MAh |
|
|
Nominal Voltage
|
9.6V |
|
|
Cycle Life
|
Higher than 80% of the Initial Capacity of the Cells |
Charge: CC@0.2C to 10.96V, then CV till current to 0.02C Rest: 30min. Discharge: 0.2C to 10.0V Temperature:20±5℃ Carry out 2000cycles |
|
Discharge cut-off voltage |
7.5V |
|
|
Charging cut-off voltage |
10.95V |
|
|
assembly method |
IFR14500-0.6AH |
3S1P |
|
Packing material |
PVC shrink |
|
|
IR |
≤ mΩ |
waiting for test result for truth sample |
|
NO |
Items |
Units: mm |
Remark |
|
|
1 |
Thickness/ |
T |
25mm |
Max. |
|
2 |
Width/ |
W |
45mm |
Max. |
|
3 |
Height/ |
H |
58mm |
Max. |
|
4 |
Cable Length |
L |
100±5 |
|
|
5 |
Printing |
|
lithium-ion 30 IFR14500 3S1P 9.6V 0.6AH TAC PIFPXXXX |
|
The period of warranty is 12 months from the date of shipment. TAC guarantees to give a replacement in case of battery with defects proven due to manufacturing process instead of the customer abuse and misuse.
The batteries should be stored at room temperature, charged to about 30% to 50% of capacity.
We recommend that batteries be charged about once per half a year to prevent over-discharge.
Prevention of short circuit within a battery pack
Enough insulation layers between wiring and the cells shall be used to maintain extra safety protection.
The battery pack shall be structured with no short circuit internally, which may cause generation of smoke or firing.
Packing the battery with UN38.3 rules with standard export carton
