Lithium Polymer Cell GSP555376 3.7V 2300mAh Batteries for Aeromodelling Toy
The batteries used in aeromodelling toy
Place of Origin Guangdong China (Mainland)
Brand Name TAC
Model Name; GSP555376(Rechargeable Gsp555376)
Battery Type :polymer lithium-ion battery
Nominal Voltage 3.7V
Nominal Capacity 2300mAh
Size :5.5mm(T)*53mm(w)76mm(h)
Detail Specification
No. |
Item |
Rated Performance |
Remark |
|
1 |
Rated Capacity |
Minimum |
2300mAh |
Standard discharge(0.2C |
2 |
Nominal Voltage |
3.7V |
Mean Operation Voltage |
|
3 |
Voltage at end of |
3.0V |
Discharge Cut-off Voltage |
|
4 |
Charging Voltage |
4.2±0.03V |
|
|
5 |
AC (1KHz) |
≤80mΩ |
|
|
6 |
Standard charge |
Constant Current 0.5C5A |
Charge time : |
|
7 |
Standard discharge |
Constant current |
|
|
8 |
Fast charge |
Constant Current 1C5A |
Charge time : Approx 2.5h |
|
9 |
Fast discharge |
Constant current 1 C5A |
|
|
10 |
Maximum |
1 C5A |
|
|
11 |
Maximum continuous |
1.5 C5A |
|
|
12 |
Operation temperature range |
Charge: 0~45℃ |
60±25%R.H. |
|
Discharge: -20~60℃ |
||||
13 |
Storage temperature |
Less than 1 year: -20~25℃ |
60±25%R.H. |
|
Less than 3 months: -20~40℃ |
||||
14 |
Weight |
Approx :40g |
Bare cell |
|
15 |
Cell dimension |
Length: Max.76mm |
Initial dimension |
|
Width: Max.53mm |
||||
Thickness: Max. 5.5mm |
Car starter jumper
Global localization satellite GPS
Bluetooth, camera
Portable type :media products(Mp3, Mp4, DVD),notebook, tablet PC,
the electronic toy, e-bike, model ship,the power tool,the multi-purpose PDA telephones.
Test Report Photos for Lithium Polymer Cell
Similar Model for Lithium Polymer Cell GSP555376 3.7V 2300mAh Batteries for Aeromodelling Toy
Model |
Nominal Voltage |
Typical Cape |
Dimension(mm) |
||
(mm) |
Thickness |
Width |
Height |
||
073496DHP |
3.7 |
2100 |
7.8 |
34 |
96 |
LP0567100 |
3.7 |
3400 |
4.8 |
67 |
100 |
LP066166 |
3.7 |
2750 |
6.1 |
61 |
66 |
LP555376 |
3.7 |
2300 |
5.6 |
53 |
76 |
LP085065 |
3.7 |
2600 |
7.8 |
50 |
65 |
LP085080 |
3.7 |
3400 |
8 |
50 |
80 |
LP0845131 |
3.7 |
5100 |
7.5 |
45 |
131 |
LP0831134 |
3.7 |
4000 |
8.1 |
31 |
132 |
LP5510010 |
3.7 |
5600 |
5.5 |
100 |
100 |
LP605590 |
3.7 |
3400 |
6 |
55 |
90 |
LP9051109 |
3.7 |
5500 |
9 |
51 |
109 |
LP9551119 |
3.7 |
6800 |
9.5 |
51 |
119 |
*LP7044125 |
3.7 |
4200 |
7 |
44 |
125 |
*LP7545135 |
3.7 |
4500 |
7.5 |
45 |
135 |
LP704374 |
3.7 |
2200 |
7 |
43 |
74 |
LP854374 |
3.7 |
3000 |
8.5 |
43 |
74 |
Q1. Can I have a sample order?
Yes, we are delighted to get your sample order to test and Customized is available.
Normally the samples is free if the samples less than 2 pcs single cell
Q2. What about the lead time?
Sample needs 5~10 days when we have battery stock
mass production time needs 25~30 days if the battery have not stock
Q3. Do you have any MOQ limit?
Yes, The MOQ for mass production is 5000pcs, but we can accepted partial delivery
there is no MOQ if you just need sample ( we have the battery cell stock )
Q4. How do you ship the goods and how long does it take to arrive?
Sampled will be shipped by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive.
Airline and sea shipping also optional depend on your quantity
Q5. How to proceed an order?
Firstly share your requirements or application to us , we will suggestion the good solution
Secondly We quote according to your requirements or our suggestion specification
Thirdly customer confirm the PI for samples or mass order
Fourthly We arrange the production after we get the payment from the buyer
Q6. Is it OK to print my logo on product?
Yes.OEM , ODM are welcome
