No. |
Item |
Rated Performance |
Remark |
|
|
1 |
Rated Capacity |
Minimum |
800mAh |
Standard discharge(0.2C |
|
2 |
Nominal Voltage |
3.7V |
Mean Operation Voltage |
|
|
3 |
Voltage at end of |
3.0V |
Discharge Cut-off Voltage |
|
|
4 |
Charging Voltage |
4.2±0.03V |
|
|
|
5 |
AC (1KHz) |
≤160mΩ |
|
|
|
6 |
Standard charge |
Constant Current 0.5C5A |
Charge time : Approx 4.0h |
|
|
7 |
Standard discharge |
Constant current 0.2 C5A |
|
|
|
8 |
Fast charge |
Constant Current 1C5A |
Charge time : Approx 2.5h |
|
|
9 |
Fast discharge |
Constant current 1 C5A |
|
|
|
10 |
Maximum Continuous |
1 C5A |
|
|
|
11 |
Maximum Continuous |
1.5 C5A |
|
|
|
12 |
Operation |
Charge: 0~45℃ |
60±25%R.H. |
|
|
Discharge: -20~60℃ |
||||
|
13 |
Storage T |
Less than 1 year: -20~25℃ |
60±25%R.H. |
|
|
less than 3 months: -20~40℃ |
||||
|
14 |
Weight |
Approx :20g |
Bare Cell |
|
|
15 |
Cell Dimension |
Length: Max.48mm |
Initial Dimension |
|
|
Width: Max.30mm |
||||
|
Thickness: Max. 7mm |
||||
Global localization satellite GPS
Bluetooth
portable type media products(Mp3, Mp4, DVD)
notebook, tablet PC
the electronic toy, e-bike, model ship
the power tool
camera
the multi-purpose
PDA telephones
1. Flexible size capacity can be pack various pack to meet the inner for equipment
2 protect board for li polymer battery to make battery more stable;
3.With short-circuit production function, safe and reliable;
4.Li-polymer battery up to 500 cycles life,low self-discharge,no memory effect;
5.Factory support technology solution and competitive price whatever cell and pack
6.Li polymer battery with CE/ROSH/SGS/UL/MSDS/UN38.3/IEC61233 standard.
Trading Detail:
1) Packing: Industrial packing (can be as customer's requirements)
2) MOQ: 1000pcs (Small trial order accepted)
3) Delivery time: Usually 7 days with stock ,and 20-25 working days after payment for battery without stock
4) Payment term: T/T, LC ,Paypal
the capacity from 100mah to 20000mah
| model | mAh | V | T: mm | W : mm | L /mm | mΩ | g | Current |
| W752530-450 | 450 | 3.7 | 7.5 | 24.32 | 29.71 | 67.6 | 9.6 | 1C |
| W702035-450 | 450 | 3.7 | 6.96 | 20.1 | 35.73 | 57.3 | 8.74 | 1C |
| W652240-500 | 500 | 3.7 | 6.61 | 22.14 | 40.04 | 64.1 | 9.8 | 1C |
| W852330-520 | 520 | 3.7 | 8.03 | 23.6 | 30.8 | 61.3 | 9.68 | 1C |
| W503046-700 | 700 | 3.7 | 4.69 | 30.19 | 46.39 | 42 | 13.46 | 1C |
| W752440-740 | 740 | 3.7 | 7.65 | 23.95 | 41.22 | 44.7 | 11.95 | 1C |
| W552072-800 | 800 | 3.7 | 5.45 | 20.04 | 72.72 | 35.4 | 15.11 | 1C |
| W603048-850 | 850 | 3.7 | 5.6 | 30.5 | 48.8 | 39.6 | 15.88 | 1C |
| W503450-850 | 850 | 3.7 | 4.86 | 34.5 | 50.8 | 35.5 | 16.21 | 1C |
| W653046-900 | 900 | 3.7 | 6.75 | 29.94 | 46.68 | 38.8 | 17.25 | 1C |
| W823038-900 | 900 | 3.7 | 8.64 | 30.5 | 38.6 | 52.2 | 17.43 | 1C |
| W602072-950 | 950 | 3.7 | 5.96 | 19.46 | 71.91 | 32.8 | 17.02 | 1C |
| W503060-960 | 960 | 3.7 | 5.04 | 29.17 | 60.7 | 30 | 18.17 | 1C |
| W603450-1000 | 1000 | 3.7 | 6.12 | 35.18 | 50.71 | 36.5 | 19.53 | 1C |
| W305069-1000 | 1000 | 3.7 | 2.79 | 50.4 | 69.3 | 30 | 19.89 | 1C |
| W553055-1000 | 1000 | 3.7 | 6.17 | 30.5 | 55.8 | 37.7 | 19.6 | 1C |
| W103228-1000 | 1000 | 3.7 | 11.13 | 31.64 | 28.42 | 60.9 | 17.71 | 1C |
| W752080-1000 | 1000 | 3.7 | 6.62 | 20.98 | 80.61 | 27.9 | 19.8 | 1C |
| W753048-1100 | 1100 | 3.7 | 6.93 | 29.65 | 49.21 | 17.8 | 19.92 | 1C |
| W503562-1100 | 1100 | 3.7 | 4.6 | 35.5 | 62.6 | 30.6 | 21.36 | 1C |
| W722562-1200 | 1200 | 3.7 | 7.45 | 25.3 | 62.7 | 31.5 | 21.05 | 1C |
| W804044-1400 | 1400 | 3.7 | 8.05 | 40.4 | 45.2 | 36.3 | 26.18 | 1C |
| W584448-1400 | 1400 | 3.7 | 5.7 | 44.24 | 48.39 | 39.1 | 25 | 1C |
| W753650-1400 | 1400 | 3.7 | 7.42 | 36.59 | 50.64 | 33.8 | 25.93 | 1C |
| W553760-1400 | 1400 | 3.7 | 5.44 | 36.77 | 59.96 | 29.3 | 24.32 | 1C |
| W953048-1420 | 1420 | 3.7 | 10.6 | 30.4 | 48.9 | 38.6 | 26.14 | 1C |
| W423885-1450 | 1450 | 3.7 | 4.14 | 38.6 | 86 | 22.2 | 28.3 | 1C |
| W6020120-1450 | 1450 | 3.7 | 5.42 | 19.96 | 121.48 | 23.6 | 27.42 | 1C |
| W394170-1450 | 1450 | 3.7 | 4.04 | 41.5 | 70.5 | 26.4 | 25.61 | 1C |
| W103048-1500 | 1500 | 3.7 | 9.77 | 30.25 | 48.64 | 37.6 | 28.25 | 1C |
| W583273-1500 | 1500 | 3.7 | 5.82 | 32.6 | 73.7 | 27.3 | 27.92 | 1C |
| W903448-1500 | 1500 | 3.7 | 8.96 | 34.4 | 48.7 | 37.7 | 36.6 | 1C |
| W952362-1500 | 1500 | 3.7 | 9.82 | 23.6 | 62.8 | 30.5 | 26.55 | 1C |
| W703562-1600 | 1600 | 3.7 | 7.04 | 35.4 | 62.7 | 30.5 | 30.24 | 1C |
| W7517123-1600 | 1600 | 3.7 | 7.13 | 17.53 | 122.71 | 21.4 | 20.34 | 1C |
| W683759-1600 | 1600 | 3.7 | 6.24 | 36.83 | 59.33 | 30.7 | 28.28 | 1C |
| W953450-1700 | 1700 | 3.7 | 9.37 | 34.13 | 50.81 | 36.1 | 31.79 | 1C |
The batteries were putted in customize plastic transparency tray
10-20 pcs for one tray, 8-10 trais for one carton depond on the size
